Solar Eclipse observations from

Udaipur Solar Observatory - 21 June 2020


MAST



Small field

(3 arcmin) 50 cm Multi-Application Solar Telescope with 2m focal length



Imagers:

G-Band

H-Alpha

Guider



G-Band Imager

Telescope: MAST

wl: 4305A (10A)

FOV: ~2.5 arcmin

Camera:

PCO Imaging



H-Alpha Imager

Telescope: MAST

wl: 6563A (0.5A)

FOV: ~2.5 arcmin

Camera: Photonmax



Guider Imager

Telescope: MAST

wl: whitelight

FOV: Full Sun

Lens: Sigma 740 mm focal length

Camera: Prosilica





Celestron



20 cm Schmidt- Cassegrain Telescope with 2m focal length



Imagers:

Full Disk



Full Disk Imager

Telescope: Celestron

wl: 6563A (2A)

FOV: Full Sun

Camera: FLI





GONG



8 cm aperture lens with 1m focal length



Imagers:

H-Alpha

Full Disk





About Solar Eclipse



gband



Solar eclipse is one of the fascinating sky-gazing events. Ever since its first observation, it has revealed many basic principles in Physics. With the advent of technology, we are able to track, record and predict this spectacular (amazing) event.
The last solar eclipse occurred on 26 December 2019 was annular and the event was recorded as a partial eclipse from the Udaipur Solar Observatory (USO).
We are going to observe the first solar eclipse of this year on 21st  June, which is also an annular eclipse. A solar eclipse is called annular when the moon does not completely occult the sun leaving an outer bright ring or annulus visible. A partial eclipse when the moon covers only some part of the Sun. In northern India, some locations will witness the annular eclipse.
Specifically, in Udaipur (24.58 deg N, 73.71 deg E), the eclipse will be a partial type. The eclipse will begin from 10:07 am (IST), peaks at 11:47am (IST) and ends at 1:36 pm (IST). Maximum magnitude of the eclipse will be 0.86 and the complete duration of the event will be 3 hours 29 minutes. At USO the eclipse observations will be carried out with the SPAR telescope, in full-disk format, the images will be updated on the PRL/USO website.
( https://www.prl.res.in/~uso/eclipse21062020/Eclipse_USO.jpeg ).

The partial eclipse images will also be recorded in H-alpha by the Global Oscillation Network Group (GONG) telescope installed at USO, Udaipur, the images can be viewed in at the following link.
( https://gong2.nso.edu/products/tableView/table.php?configFile=configs/hAlpha.cfg )
